Item

Value

Remarks

Working performance specification

Max. rated total lifting capacity kg

70000

Max. load moment of basic boom kN.m

2352

Max. load moment with max. main boom length kN.m

1098

Max. lifting height of basic boom m

12.2

Max. lifting height of main boom m

44.2

Without considering boom deformation

Max. lifting height of fly jib m

60.2

Working speed

Max. speed of single rope on main winch m/min

135

The 4 th layer of

drum

Max. speed of single rope on auxiliary winch m/min

110

The 2 nd layer of drum

Derricking time of boom s

57

Telescopic time of boom s

107

Slewing speed r/min

1.8

Traveling specification

Max. traveling speed km/h

75

Max. gradeability %

37

Min. turning circle diameter m

24

Min. ground clearance mm

280

Oil consumption per hundred kilometers L

46

Mass specification

Deadweight of crane in traveling condition kg

45000

Complete vehicle kerb mass kg

44870

Front axle load kg

19000

Rear axle load kg

26000

Dimension specification

Overall dimensions(L×W×H) mm

14100×2750×3750

Base on outriggers m

6.00

Distance between outriggers m

full extended 7.60, half extended 5.04

Main boom length m

11.6~44.0

Main boom angle °

-2 ～ 80

Fly jib length m

9.5 , 16

Offset angle of fly jib °

0 , 30
